Self Locking Lock Cable Grippers Satin Plated Brass Material Gripper

We have a large variety of sign, art, and picture hanging cable grippers to ensure

that we are able to provide a complete solution for your project.

Description

1. Item Name:Satin Plated Cable Gripper

2. Material:Brass

3. Measurement:Φ11*22mm

4. Thread Size:M8 Male Thread

5. Finishing Color:Satin;Or Customize

6. Application:

The cable grippers are suited for a wide variety of applications,

Such as Lighting Products,Signs,Dispalys, Artwork, Graphics and many other items,

And offer the perfect solution for the suspending system.

7. Safe Working Load:10KG(For reference only)

What types of Cable Grippers are available?

There’s a wide variety, but there are two distinct types. The Straight-Thru’ or standard Gripper

allows the cable to exit through the Gripper’s thread into the fixture. The Side-Cable-Exit Gripper

allows the cable to exit the Gripper from the side of the body before the Gripper enters the fixture, eliminating the possibility of a short circuit.

What are Grippers made of?

Most are made of nickel-plated brass. The internal mechanism is stainless

steel and brass.Other finishes include satin , chrome and black zinc.

Can I use the Grippers out of doors?

Generally not, but our products may be used outside for temporary rigging purposes.

Can I use your products for indoor pools?

The chemical atmosphere in most indoor pool areas can be detrimental to certain

materials over time.Please consult with the Sales Team for more information.

Cable Gripper is the safest, strongest, simplest and most versatile system of its kind on the market today, we are offering thousands of precision-made parts to fit almost every conceivable application.

The key component, the Self-Locking Cable Gripper, is a unique, self-locking, completely adjustable device, designed to securely lock onto a large range of 7x7 stranded aircraft cables.

It requires no tools to adjust; up or down, down or up - as often as you like.

Cable Grippers are sophisticated in design but simple to use to hang your pictures or fine art.

Here’s how it works:

Insert the cable into the plunger and slide the gripper to the desired position. Where it stops it locks.

To re-adjust, simply depress the plunger with your fingertip and move the gripper to a new position. Release the plunger to lock.

The 3-ball gripping mechanism is spring-loaded and allows the gripper to move freely up the cable. It cannot move down unless the plunger is depressed.

While there is any weight at all on the gripper, the plunger cannot be depressed. An optional “safety nut” or “safety cap” can be added to completely lock the mechanism in both directions. The Greater The Weight, The Stronger It Grips.
